Modular design
Flexible configuration
Compact structure
Fast expansion
| Items | Parameters | Parameters |
|---|---|---|
| Model | SRBE-200 | SRBE-300 |
| AC parameters (grid-connected) | ||
| Rated power | 100KW | 150KW |
| Rated voltage | 400V | 400V |
| Rated current | 144A | 216A |
| Voltage range | 320V～460V | 320V～460V |
| Rated frequency | 50/60Hz | 50/60Hz |
| Frequency range | 45～55/55～65Hz | 45～55/55～65Hz |
| THDI | ＜3% | ＜3% |
| Power factor | 1（Set 0.8 lead~0.8 lag） | 1（Set 0.8 lead~0.8 lag） |
| AC system | 3W+N+PE | 3W+N+PE |
| AC parameters (off-grid) | ||
| Rated power | 100KW | 150KW |
| Rated voltage | 400V | 400V |
| Rated current | 144A | 216A |
| THUD | ≤2% Linear | ≤2% Linear |
| Rated frequency | 50/60Hz | 50/60Hz |
| Overload capacity | 110%-10 Min, 120%-1 Min | 110%-10 Min, 120%-1 Min |
| Battery | ||
| Battery type | Lithium iron phosphate battery | Lithium iron phosphate battery |
| Rated charge/discharge power | 100kW/100kW | 150kW/150kW |
| Maximum charge/discharge power | 120kW/120kW | 180kW/180kW |
| Rated capacity | 192kWh | 288kWh |
| Nominal voltage | 768V | 1152V |
| Operating voltage range | 672V～864V | 940.8V～1209.6V |
| Rated operating ratio | 0.5C | 0.5C |
| Routine data | ||
| Dimension (width/depth/height) | 1800*1000*2200mm | 1800*1300*2200mm |
| Weight | 2000kg | 3000kg |
| Working ambient temperature | -25℃～+55℃ | -25℃～+55℃ |
| Humidity | 0～95% Non-condensing | 0～95% Non-condensing |
| Protection level | IP54 | IP54 |
| Noise | ＜65dB | ＜65dB |
| Elevation | 5000m (Capacity reduction of 3000+ meters) | 5000m (Capacity reduction of 3000+ meters) |
| Standby power consumption | ＜30W | ＜30W |
| Cooling mode | Intelligent air cooling | Intelligent air cooling |
| Communication | ||
| Display | Touch LCD display | Touch LCD display |
| Communication interface | RS485/CAN | RS485/CAN |
| Operating mode | ||
| Grid-connected operation | Yes | |
| Off-grid operation | Yes | |
